Description
Just the right balance — that’s the essence of Xroad! This Xroad ES(sential) version makes no compromise on quality, offering the best riding experience whether you’re exploring country trails or navigating the urban jungle. Equipped with the Active Line Plus motor, it delivers just the right amount of support for every ride.
Product Details and Specifications
User Manual
Spécifications
Cadre
Cadre
Xroad, 6061 T4-T6 alloy, variable thickness hydroformed tubes, Bosch PowerTube battery integration (vertical), integrated cable routing
Suspension
Fourche
SR Suntour, XCM32-ATB, preload adjustment & lockout function, 80mm travel
Système moteur
Moteur
Bosch, Active Line Plus, Smart System, 50Nm
Batterie
Bosch, PowerTube 500Wh, vertical, Smart System
Autonomie
125 km
Chargeur
Bosch, 2Ah
Commande
Bosch, Purion 200, Smart System
Transmission
Cassette
Shimano, CUES, CS-LG300 9-speed, 11-36T
Chaîne
Shimano, CN-LG500, 120 links
Manette
Shimano, CUES, SL-U4000-9R, 9-speed
Pédalier
Moustache, aluminum, 170mm Gen3 motor
Dérailleur
Shimano, CUES, RD-U3020, 9-speed
Plateau
Narrow-Wide, 40 teeth
Freins
Frein avant
Shimano, MT200, hydraulic disc
Frein arrière
Shimano, MT200, hydraulic disc
Disque avant
Shimano, 180mm
Disque arrière
Shimano, 160mm
Roues
Moyeu avant
Shimano, 32H, 9x100mm, QR (Quick Release)
Moyeu arrière
Shimano, 32H, 9x135mm, QR (Quick Release)
Jante avant
Moustache, asymmetric, alloy 6061E, welded, 32 holes, 27.5", internal width 23mm
Jante arrière
Moustache, asymmetric, alloy 6061E, welded, 32 holes, 27.5", internal width 23mm
Pneus
Schwalbe, Smart Sam, 27.5x2.25
Cockpit
Selle
Selle Royal, Wave
Tige de selle
Moustache, alloy, 31.6mm, 350mm
Collier de selle
Moustache, alloy, 34.9mm
Guidon
Moustache, ergonomic, alloy, 680mm, 25° backsweep
Potence
Moustache, alloy, adjustable, 90mm
Jeu de direction
FSA, No 57B
Poignées
Ergonomic, dual-density
Équipement
Eclairage avant
AXA, NXT, 30 lux, powered by main battery
Eclairage arrière
Spanninga, Presto2Guard, powered by main battery
Béquille
Moustache, adjustable
Garde-boue
Moustache, alloy, double wall design, w/alloy stays
Pédales
Alloy platform with reflectors
Porte-bagages avant
Moustache, alloy, removable QL3 lateral fixation, MIK HD platform
Caractéristiques
Taille
Standard
S (1.55 – 1.70m)
M (1.68 – 1.83m)
L (1.80 – 1.95m)
XL (1.90 – 2.05m)
Open
S (1.49 – 1.61m)
M (1.59 – 1.76m)
L (1.74 – 1.90m)
Couleur
Titanium, Dark Blue, Chalk
Poids
26.2 kg
PTAC
135 kg
Garantie
5 years frame and fork Moustache Bikes - 2 years motor, battery
* Les prix, modèles et spécifications peuvent changer sans préavis.
