Description
Dimanche 29 Gravel 4 is the pen you need to write your own stories, your daily adventures or your long-distance rides. It’s available with or without equipment, so you can let your imagination run wild! Have fun every day, free yourself from limitations, take the trail, take a lovely country road, explore, smile!
EQ model is equipped with a mudguard, QL3-compatible luggage rack, and front lighting.
Specifications
Frame
Frame
Dimanche 29, 6061 T4-T6 alloy, variable thickness hydroformed tubes, CompactTube integration and internal cable routing
Suspension
Fork
Dimanche 29, full carbon, tapered steerer tube 1"1/8-1"1/2 - FlatMount 180mm direct brake mount - 12x100mm Axle - 50mm offset - For tires in 700x50 - Mounts for mud-guard and luggage racks
Motor system
Motor
Bosch, Performance Line SX, Smart System, 55-60Nm
Battery
Bosch, CompactTube 400Wh, Smart System
Autonomy
90 km
Charger
Bosch, 2Ah
Display
Bosch, Kiox 300, Smart System
Remote
Bosch, System Controller and Mini Remote, Smart System
Transmission
Cassette
SRAM, Eagle, PG-1230 12-speed, 11-50T
Chain
Sram, SX Eagle, 12-speed, 120 links
Cranks
FSA, forged aluminum, 165mm
Rear derailleur
SRAM, Apex Eagle, 12-speed
Chainring
SRAM, Narrow-Wide, 44 teeth, chainguard
Brakes
Front brake
SRAM, Apex, hydraulic disc
Rear brake
SRAM, Apex, hydraulic disc
Front rotor
SRAM, Paceline, 160mm
Rear rotor
SRAM, Paceline, 160mm
Wheels
Front hub
Moustache, 24H, 12x100mm, thru axle
Rear hub
Moustache, 24H, 12x142mm, thru axle
Front rim
Moustache, al:30, alloy 6061, welded, 24 holes, 700c, 22mm internal width
Rear rim
Moustache, al:30, alloy 6061, welded, 24 holes, 700c, 22mm internal width
Tires
Maxxis, Rambler, 700x50C, Tanwall
Cockpit
Saddle
Selle Royal, VIVO
Seatpost
EXA, 860i, suspended dropper-post w/remote lever, 31.6mm, 75mm
Seat clamp
Moustache, alloy, 34.9mm
Handlebar
Moustache, alloy, rise 10, drop 129, reach 65, flare 16°, 420mm
Stem
Moustache, aluminum, suspended 10-20mm travel, 70mm
Headset
Acros, AZF-725, sealed bearings, internal routing
Grips
Moustache bar tape, gel 2.5mm
Equipment
Front light
Trelock, Lighthammer, 80 lux, powered by main battery
Rear light
Spanninga, Presto2Guard, powered by main battery
Kickstand
Moustache, adjustable
Mudguard
Moustache, stable and perfect protection thanks to the integrated mudflap
Pedals
Alloy platform with reflectors
Rear carrier
Moustache, alloy, light, removable QL3 lateral fixation
Front carrier
Optional extra: Moustache, Alloy, compatible with QL3 bags and accessories
Features
Size
Standard
S (1.53 – 1.68m)
M (1.66 – 1.81m)
L (1.79 – 1.94m)
XL (1.92 – 2.07m)
Open
S (1.43 – 1.55m)
M (1.53 – 1.68m)
L (1.66 – 1.81m)
Colour
Black
Weight
18.9 kg
GVWR
120 kg
Warranty
5 years frame and fork Moustache Bikes - 2 years motor, battery
* Prices, models, and specifications are subject to change without notice.
